Ignition transformers TZI and TGI are designed for high-voltage spark ignition of gas burners and gas-ignited or directly ignited oil burners. The ignition transformers can also be used on burners with single-electrode operation; the ignition current and ionization current flow over a common electrode. Ignition transformer TZI fulfils the requirements for enclosure IP 20. It is suitable for installation in a control cabinet. Ignition transformer TGI in its die-cast aluminium housing meets the requirements for enclosure IP 65. It is suitable for on-site mounting near to the burner.

• Electrical ignition of gas burners
• Ignition and burner control with a single electrode possible
• For installation in a control cabinet or wall mounting
• Complying with EN 61558-2-3
• TZI 7,5-20/33R complies with CSA

Additional Information:

• Item Code: TZI7-5-12-100w
• Delivery Time: Ex-stock

For high-voltage spark ignition of gas burners and gas- or directly-ignited oil burners, the TZI and TGI ignition transformers are made. The ionization and ignition currents of burners that operate with a single electrode can also be powered by ignition transformers; these burners share one electrode. The TZI ignition transformer satisfies IP 20 enclosure criteria. Installing it in a control cabinet is appropriate. With its die-cast aluminum casing, the ignition transformer TGI satisfies IP 65 enclosure requirements. It can be mounted close to the burner on-site.
